The Arco 600-P series portable vacuums incorporate a positive displacement vacuum producer to handle your heavy-duty cleaning applications. Extremely high vacuum levels mean consistent suction power when picking up heavy material. Ideal for metal chip recovery, slurries, blast media & applications requiring long vertical lifts. The 600-S series has a guaranteed 24 hour per day operation. Optional features for this industrial vacuum also include HEPA discharge or inline filter, explosion proof motors and in-line separators of all sizes. Our industrial vacuums can collect a variety of materials. Click here to view a full list of the material types that we can move.
ARCO Wand 600-P Vacuum Features
- Slow speed brushless motor means no armature or bearing problems
- Guaranteed 24-Hour per-day operation
- Patented filter cleaning mechanism
- 1-1/2 HP Thru 10 HP TEFC General purpose motors
- Vacuum relief valve prevents motor overload
- Heavy duty cloth filter
- Oversized wheels and casters for portability
- Cast Iron Housing & Cast Steel Impellers
- All units runs under 85DBA
- Power Coat finish
- Check valve prevents unit from running in reverse
- All units come complete with NEMA 1 motor starters
- Stationary units available
Photo Gallery
SPECIFICATIONS
| MODEL | CAPACITY | CFM | WATERLIFT | POWER | NOISE LEVEL | DIMENSION L,W,H | WEIGHT |
|---|---|---|---|---|---|---|---|
| 615 P 1.5-HP | 11 Gallon | 90 | 7.5” HG | 230-460/3 | 80 DBA | 54” x 22” x 58” | 440 LBS |
| 620 P 2 H.P. | 11 Gallon | 125 | 8.0 HG | 230-460/3 | 77 DBA | 54" x 22" x 59" | 460 LBS |
| 630 P 3 H.P. | 11 Gallon | 150 | 8.5 HG | 230-460/3 | 78 DBA | 54" x 22" x 59" | 560 LBS |
| 650 P 5 H.P. | 11 Gallon | 175 | 8.5 HG | 230-460/3 | 78-80 DBA | 54" x 22" x 59" | 580 LBS |
| 675 P 7.5 H.P. | 11 Gallon | 220 | 8.5 HG | 230-460/3 | 81-83 DBA | 54" x 22" x 59" | 605 LBS |
|
610 P 10 H.P. |
11 Gallon | 240 | 8.5 HG | 230-460/3 | 83 DBA | 54" x 22" x 59" | 635 LBS |
OPTIONS
- HEPA Filtration available
- Explosion-Proof Motors & NEMA 7/9 Starters
- Separators for wet recovery & larger capacity
- Pneumatic tires and wheels
- Central vacuum system tube & fittings
- Special fine particulate filters
- Complete assortment of 1-1/2" & 2" Hose & Cleaning Tools
