Our industrial line of Bulk Material Vacuum Systems and Bulk Material Handling Vacuums for mass quantity cleaning. Our Powerlift Bulk Material Vacuum System Units come standard with removable storage hoppers with up to 40 Cu.Ft. of storage capacity. Up to 16" HG" of continuous vacuum for mass-quantity removal. Need to move mountains of material? This Powerlift bulk material vacuum system is the unit. Ideal for bulk conveying over long distances.
American Vacuum Company now offers the ability to rent out Powerlift Bulk Material Vacuum systems. Contact us today for more information on how to rent our Bulk Material Vacuum systems.
Features
- Dependable cast iron Positive Displacement pump
- Guaranteed 24-Hour per-day operation
- Abrasion-resistant Inlet wear plate
- TEFC High-efficiency motors - standard
- Primary filtration efficient to 1 micron
- Built-in Forklift channels for easy transport
- First stage cyclonic internal separation
- Secondary In-Line filter - Standard
- All units runs under 85 DBA
- Special high volume separators for your large recovery applications
Photo Gallery
SPECIFICATIONS
| MODEL | CAPACITY | CFM | WATERLIFT | POWER | NOISE LEVEL | WEIGHT |
|---|---|---|---|---|---|---|
| PL-20CV | 1.33 Cu.Ft. | 400 | 16" HG | 230/460/3 | 82 | 3350 LBS |
| PL-25CV | 1.33 Cu.Ft. | 525 | 16" HG | 230-460/3 | 85 | 3450 LBS |
| PL-30CV | 1.33 Cu.Ft. | 650 | 16" HG | 230/460/3 | 87 | 3500 LBS |
| PL-40CV | 2.0 Cu.Ft. | 850 | 16" HG | 230-460/3 | 85 | 4820 LBS |
| PL-50CV | 2.0 Cu.Ft | 1050 | 16" HG | 230/460/3 | 87 | 4900 LBS |
| PL-75CV | 2.5 Cu.Ft | 1550 | 16" HG | 230/460/3 | 90 | 7500 LBS |
OPTIONS
- In-Line HEPA Filtration available
- Explosion-Proof Motors & NEMA 7/9 Starters
- Regenerative Vacuum producers
- Central vacuum system tube & fittings
- Gas or Diesel Powered Units
- Complete assortment of 2", 3" & 4" Hose & Bulk Cleaning Tools
